Print Maximum Printing Resolution 4800 (horizontal)*1 x 600 (vertical) dpi Print Head / Ink Type: FINE Cartridge Number of Nozzles: Total 1,280 nozzles Ink Droplet Size (minimum): 2pl Ink Cartridge: PG-745S, CL-746S (PG-745, CL-746, PG-745XL, CL-746XL � Optional) Print Speed Based on ISO / IEC 24734. Click here for summary report Click here for Document Print and Copy Speed Measurement Conditions Document: Colour*2: ESAT / Simplex: Approx. 4.0 ipm Document: B/W*2: ESAT / Simplex: Approx. 8.0 ipm Printable Width Up to 203.2 mm (8 inch) Bordered Printing: Top margin: 3 mm, Bottom margin: 16.7 mm, Left / Right margin: each 3.4 mm (LTR / LGL: Left: 6.4 mm, Right: 6.3 mm) Recommended Printing Area Top Margin: 31.6 mm Bottom Margin: 29.2 mm Paper Size A4, A5, B5, LTR, LGL, 4 x 6", 5 x 7", Envelopes (DL, COM10), Custom size (width 101.6 - 215.9 mm, length 152.4 - 676 mm) * F4 is possible via custom size settings. Paper Handling (Rear Tray) (Maximum Number) Plain Paper A4, A5, B5, LTR = 60, LGL = 10 Photo Paper Plus Glossy II (PP-201) 4 x 6" = 20 Glossy Photo Paper "Everyday Use" (GP-501) Glossy Photo Paper "Everyday Use" (GP-601) 4 x 6" = 20 Envelope European DL / US Com. #10 = 5 Paper Weight Cassette: Plain Paper: 64 -105 g/m2, Canon specialty paper: max paper weight: approx. 275 g/m2 (Photo Paper Plus Glossy II (PP-201) Ink End Sensor Dot count Print Head Alignment Manual Scan*4 Scanner Type Flatbed Scanning Method CIS (Contact Image Sensor) Optical Resolution*5 600 x 1200 dpi Selectable Resolution*6 25 - 19200 dpi Scanning Bit Depth (Input / Output) Grayscale: 16 / 8-bits Colour: 48 / 24-bits (RGB each 16 / 8-bits ) Line Scanning Speed*7 Grayscale: 1.2 ms/line (300 dpi) Colour: 3.5 ms/line (300 dpi) Scanning Speed*8 Reflective: A4 Colour / 300 dpi Approx. 14 sec Maximum Document Size Flatbed: A4 / LTR (216 x 297 mm) Copy*9 Maximum Document Size A4 / LTR (216 x 297 mm) Compatible Media Size: A4, LTR Type: Plain Paper Image Quality Plain Paper: Fast, Standard Copy Speed*10 Based on ISO / IEC 29183. Click here for summary report Click here for Document Print and Copy Speed Measurement Conditions Document: Colour: sFCOT / Simplex: Approx. 31 sec Document: Colour: sESAT / Simplex: Approx. 1.6 ipm Multiple Copy Black / Colour 1 - 21 pages System Requirements (Please visit www.canon-asia.com to check OS compatibility and to download the latest driver updates.) Windows: Windows 8 / Windows 7 / Window Vista / Windows XP Macintosh: Mac OS X v10.7.5 and later General Interface USB 2.0 Hi-Speed Operating Environment Temperature: 5 - 35�C Humidity: 10 - 90% RH (no dew condensation) Storage Environment Temperature: 0 - 40�C Humidity: 5 - 95% RH (no dew condensation) Power AC 100 - 240 V, 50/60 Hz Power Consumption Standby (scanning lamp is off) (USB connection to PC): Approx. 1.0 W OFF: Approx. 0.4 W Copying*11: (USB connection to PC) Approx. 9 W Environment Regulation: RoHS (EU, China), WEEE (EU) Eco-Label: EPEAT Dimension (W x D x H) Approx. 426 x 306 x 145 mm Weight Approx. 3.5 kg
